Crossed Roller Bearings for High-rigidity Rotary Mechanisms

Application

Application Challenges

Structural Deformation

Bearing and housing deformation can reduce positioning and transmission accuracy.

Combined Loads

Rotary mechanisms often carry radial, axial and tilting moment loads simultaneously.

High Moment Capacity

Large overhung loads require strong resistance to tilting.

Accurate Rotation

High-rigidity mechanisms still require low runout and smooth torque.

Long-term Rigidity

Repeated loads must not cause excessive wear or preload loss.

Products

Recommended Crossed Roller Bearing Series

RAU Series
Compact solution where low mass and rigidity must be balanced.
RU Series
Integrated rings and mounting holes for rigid direct installation.
CRBH Series
High-rigidity series for heavy combined and moment loads.
RE Series
Inner-ring rotation solution for compact output mechanisms.
RB Series
Versatile crossed roller bearing for rigid rotary support..
SX Series
Compact separable type for restricted installation space.
XSU Series
Integrated mounting-hole bearing for high-rigidity rotary assemblies.

Selection

Selection Information

Information Customers Can Provide

Rotary mechanism type and layout
Radial load, axial load and tilting moment
Overhang distance and support span
Operating speed and motion cycle
Required rigidity, deformation and runout
Preload and bearing ring rotation
Housing/shaft stiffness and mounting interface
Drawing, bearing number, lubrication and quantity

CHG Assessable Content

Suitable crossed roller bearing series
Bearing dimensions and integrated ring structure
Radial, axial and tilting moment load capacity
Precision class and runout direction
Preload, rotational torque and rigidity
Inner-ring or outer-ring rotation
Mounting-hole and adjacent structure requirements
Lubrication, sealing, quotation and delivery

ADVANTAGES

Why Choose CHG

Complete Series Coverage

CHG provides RAU, RU, CRBH, RE, RB, SX and XSU crossed roller bearing solutions for different installation structures.

Application-based Selection

Bearing series can be reviewed according to radial, axial and tilting moment loads, rigidity, runout, speed and mounting space.

Custom Manufacturing

Custom support by bearing number, dimensions, 2D/3D drawing, mounting-hole arrangement, preload and special requirements.

Quality & Inspection Support

Material certificates, dimensional inspection, precision inspection, rotational torque records and product photos can be provided according to order requirements.

Robot Joints

Precision Rotary Tables

Machine Tools

Automation Rotary Platforms

Talk to an expert

Share your requirements and we’ll help you find the right solution for your business.

Get a quick quote

We typically confirm within 24 hours.

FAQ

Crossed Roller Bearings for High-rigidity Rotary Mechanisms FAQ

Please provide the application, bearing number or dimensions, radial load, axial load, tilting moment, speed, runout or accuracy requirement, mounting structure, quantity and drawing if available.

CHG provides RAU, RU, CRBH, RE, RB, SX and XSU series crossed roller bearings.

Yes. Custom solutions can be reviewed according to 2D/3D drawings, bearing numbers, mounting-hole patterns, dimensions, preload and application conditions.

Integrated mounting-hole types simplify assembly and improve rigidity, while separable structures may suit compact or existing housings. Final selection depends on ring rotation, mounting and load requirements.

Dimensional inspection, runout inspection, rotational torque or preload records, material certificates and product photos can be provided according to order requirements.
