Crossed Roller Bearings for Optical Equipment

Application

Application Challenges

Optical Axis Stability

Small bearing deflection can affect beam alignment, image quality and tracking accuracy.

Very Low Runout

Optical systems require controlled radial and axial error motion.

Smooth Tracking

Tracking and scanning systems require low torque fluctuation and vibration.

Compact Packaging

Optical instruments often require a large clear aperture in limited space.

Environmental Stability

Temperature variation may influence alignment and preload.

Products

Recommended Crossed Roller Bearing Series

HRAU Series

Compact low-mass solution for optical stages and gimbals.

HRU Series

Integrated mounting design for camera platforms and tracking axes.

HCRBH Series

High rigidity and low runout for larger optical systems.

HRE Series

Inner-ring rotation solution for compact optical modules.

HRB Series

General precision support for optical rotary mechanisms.

HSX Series

Compact separable structure for limited axial height.

HXSU Series

Direct-mount integrated solution for precision tracking systems.

Selection

Selection Information

01

Information Customers Can Provide

Optical equipment type and axis arrangement
Payload and center-of-gravity offset
Radial, axial and tilting moment loads
Tracking or scanning speed
Required radial/axial runout and angular accuracy
Permitted friction torque and vibration
Temperature range and cleanliness
Drawing, mounting interface and quantity

02

CHG Assessable Content

Suitable crossed roller bearing series
Bearing dimensions and integrated ring structure
Radial, axial and tilting moment load capacity
Precision class and runout direction
Preload, rotational torque and rigidity
Inner-ring or outer-ring rotation
Mounting-hole and adjacent structure requirements
Lubrication, sealing, quotation and delivery

ADVANTAGES

Why Choose CHG

Complete Series Coverage

CHG provides RAU, RU, CRBH, RE, RB, SX and XSU crossed roller bearing solutions for different installation structures.

Application-based Selection

Bearing series can be reviewed according to radial, axial and tilting moment loads, rigidity, runout, speed and mounting space.

Custom Manufacturing

Custom support by bearing number, dimensions, 2D/3D drawing, mounting-hole arrangement, preload and special requirements.

Quality & Inspection Support

Material certificates, dimensional inspection, precision inspection, rotational torque records and product photos can be provided according to order requirements.

Precision Rotary Tables

Medical Equipment

Automation Rotary Platforms

High-rigidity Rotary Mechanisms

CONTACT US

Talk to an expert

Share your requirements and we’ll help you find the right solution for your business.

Get a quick quote

We typically confirm within 24 hours.

FAQ

Crossed Roller Bearings for Optical Equipment FAQ

Please provide the application, bearing number or dimensions, radial load, axial load, tilting moment, speed, runout or accuracy requirement, mounting structure, quantity and drawing if available.

CHG provides RAU, RU, CRBH, RE, RB, SX and XSU series crossed roller bearings.

Yes. Custom solutions can be reviewed according to 2D/3D drawings, bearing numbers, mounting-hole patterns, dimensions, preload and application conditions.

Integrated mounting-hole types simplify assembly and improve rigidity, while separable structures may suit compact or existing housings. Final selection depends on ring rotation, mounting and load requirements.

Dimensional inspection, runout inspection, rotational torque or preload records, material certificates and product photos can be provided according to order requirements.
