Crossed Roller Bearings for Precision Rotary Tables

Application

Application Challenges

Rotational Accuracy

Table indexing and machining accuracy depend on low radial and axial runout.

Tilting Rigidity

Workpiece and fixture overhang generate tilting moments on the table.

Drive Integration

Direct-drive, worm gear or reducer-driven tables require different bearing interfaces.

Smooth Indexing

Indexing and contouring require low torque fluctuation and stable motion.

Thermal Stability

Heat from motors and machining can influence preload and runout.

Products

Recommended Crossed Roller Bearing Series

HRAU Series

Compact option for small precision rotary and inspection tables.

HRU Series

Integrated ring and mounting-hole design for direct rotary table installation.

HCRBH Series

High rigidity and accuracy for heavy precision tables.

HRE Series

Inner-ring rotation structure for compact indexing mechanisms.

HRB Series

Standard crossed roller bearing for accurate rotary support.

HSX Series

Compact separable structure for limited-height assemblies.

HXSU Series

Integrated mounting-hole type for direct drive and precision table systems.

Selection

Selection Information

01

Information Customers Can Provide

Rotary table diameter and structure
Workpiece and fixture mass
Radial load, axial load and tilting moment
Continuous and indexing speed
Required runout and positioning accuracy
Drive type: direct drive, reducer or worm gear
Mounting holes, shaft/housing fits and preload
Drawing, current bearing number and quantity

02

CHG Assessable Content

Suitable crossed roller bearing series
Bearing dimensions and integrated ring structure
Radial, axial and tilting moment load capacity
Precision class and runout direction
Preload, rotational torque and rigidity
Inner-ring or outer-ring rotation
Mounting-hole and adjacent structure requirements
Lubrication, sealing, quotation and delivery

ADVANTAGES

Why Choose CHG

Complete Series Coverage

CHG provides RAU, RU, CRBH, RE, RB, SX and XSU crossed roller bearing solutions for different installation structures.

Application-based Selection

Bearing series can be reviewed according to radial, axial and tilting moment loads, rigidity, runout, speed and mounting space.

Custom Manufacturing

Custom support by bearing number, dimensions, 2D/3D drawing, mounting-hole arrangement, preload and special requirements.

Quality & Inspection Support

Material certificates, dimensional inspection, precision inspection, rotational torque records and product photos can be provided according to order requirements.

Machine Tools

Automation Rotary Platforms

High-rigidity Rotary Mechanisms

Optical Equipment

CONTACT US

Talk to an expert

Share your requirements and we’ll help you find the right solution for your business.

Get a quick quote

We typically confirm within 24 hours.

FAQ

Crossed Roller Bearings for Precision Rotary Tables FAQ

Please provide the application, bearing number or dimensions, radial load, axial load, tilting moment, speed, runout or accuracy requirement, mounting structure, quantity and drawing if available.

CHG provides RAU, RU, CRBH, RE, RB, SX and XSU series crossed roller bearings.

Yes. Custom solutions can be reviewed according to 2D/3D drawings, bearing numbers, mounting-hole patterns, dimensions, preload and application conditions.

Integrated mounting-hole types simplify assembly and improve rigidity, while separable structures may suit compact or existing housings. Final selection depends on ring rotation, mounting and load requirements.

Dimensional inspection, runout inspection, rotational torque or preload records, material certificates and product photos can be provided according to order requirements.
