Thin Section Bearings for Lightweight Equipment

Application

Typical Lightweight Equipment Applications

Portable Inspection Equipment

Compact rotary support for mobile inspection cameras, scanners and sensor platforms.

Mobile Robot Modules

Low-mass support for sensor turrets, steering modules and compact rotary axes.

Lightweight Gimbals

Precision support for cameras, optical sensors and stabilized payloads.

Compact Instruments

Space-saving bearings for measurement, laboratory and portable devices.

Low-Mass Rotary Actuators

Large-bore compact bearings for integrated motors, cables and lightweight drive modules.

Requirements

Application Design Requirements

Weight Reduction

Low rotating mass improves portability, acceleration and energy efficiency.

Limited Installation Space

Compact devices require a large bore with a small external envelope.

Low Friction & Efficient Motion

Small actuators benefit from consistent low torque and reduced power consumption.

Adequate Rigidity

Weight reduction must not compromise positioning stability or moment support.

Simple Integration

Flanged or custom mounting structures can reduce component count.

Types

Recommended Bearing Structures

Deep Groove Thin Section Ball Bearings

Support radial loads and moderate axial loads with low friction and compact cross-section.

Angular Contact Thin Section Ball Bearings

Suitable for combined loads, higher rotational accuracy and axial positioning requirements.

Four-Point Contact Thin Section Ball Bearings

Compact single-bearing solution for radial, axial and tilting moment loads.

Super Duplex Angular Contact Ball Bearings

High rigidity and precision for paired or integrated angular contact arrangements.

Flanged Thin Section Bearings

Simplified mounting and positioning for compact housings and lightweight rotary modules.

Selection

Selection Information

Information Customers Can Provide

Equipment type and rotary function
Existing bearing number or dimensions
Target weight and installation space
Radial, axial and moment load
Speed and acceleration
Friction torque or power limit
Drawing and mounting method

CHG Assessable Content

Suitable bearing type and structure
Cross-section and bore direction
Preload and friction direction
Rigidity and load capacity direction
Flange or mounting customization
Lubrication and sealing options
Custom feasibility

ADVANTAGES

Why Choose CHG

Weight-saving Design

Thin cross-sections help reduce rotating mass and equipment size.

Efficient Motion

Low-friction structures support responsive motion and lower actuator torque.

Large Bore Integration

Cables, motors and sensors can be integrated through the central opening.

Custom Mounting Support

Flange, dimensions, mounting holes, seals and lubrication can be customized.

Robotics

Thin section bearings for lightweight robot joints and mobile modules.

Aerospace Equipment

Low-mass bearings for airborne and satellite mechanisms.

Optical Equipment

Precision support for compact cameras and gimbals.

Automation Equipment

Compact bearings for rotary modules and indexing systems.
