Thin Section Bearings for Optical Equipment

Application

Typical Optical Equipment Applications

Camera & Imaging Systems

Compact rotary support for camera platforms, lens mechanisms and imaging modules.

Optical Gimbals

High-precision support for pan-tilt and multi-axis optical positioning systems.

Laser Scanning Equipment

Smooth low-friction rotation for scanning mirrors, rotary heads and beam-positioning mechanisms.

Telescopes & Observation Equipment

Large-bore compact support for azimuth, elevation and instrument rotation.

Precision Optical Instruments

Low runout and stable motion for inspection, alignment and measurement systems.

Requirements

Application Design Requirements

Low Runout & High Accuracy

Optical systems require stable axes and minimal radial or axial error.

Smooth Low-Friction Motion

Fine adjustment and tracking require consistent torque and low stick-slip.

Large Central Opening

Optical paths, lenses, cables or sensors may pass through the bearing bore.

Rigid Positioning

Gimbals and tracking platforms require stable support against moment loads.

Clean & Stable Operation

Lubrication and sealing should match temperature, cleanliness and maintenance needs.

Types

Recommended Bearing Structures

Deep Groove Thin Section Ball Bearings

Support radial loads and moderate axial loads with low friction and compact cross-section.

Angular Contact Thin Section Ball Bearings

Suitable for combined loads, higher rotational accuracy and axial positioning requirements.

Four-Point Contact Thin Section Ball Bearings

Compact single-bearing solution for radial, axial and tilting moment loads.

Super Duplex Angular Contact Ball Bearings

High rigidity and precision for paired or integrated angular contact arrangements.

Flanged Thin Section Bearings

Simplified mounting and positioning for compact housings and lightweight rotary modules.

Selection

Selection Information

Information Customers Can Provide

Optical equipment and axis position
Existing bearing number or dimensions
Radial, axial and moment load
Speed and motion profile
Runout and pointing accuracy
Friction torque requirement
Drawing and installation space

CHG Assessable Content

Suitable bearing type and arrangement
Precision and preload direction
Friction and lubrication options
Stiffness and moment load support
Flange or mounting customization
Runout inspection direction
Replacement compatibility

ADVANTAGES

Why Choose CHG

Precision Rotation

Solutions for low runout, smooth motion and stable optical positioning.

Compact Large-Bore Support

Large internal openings can accommodate optical paths, lenses, cables and sensors.

Custom Preload & Mounting

Preload, flange, dimensions, seals and lubrication can be reviewed according to the optical mechanism.

Inspection Support

Dimensional, rotational accuracy and product inspection documentation can be provided according to order requirements.

Precision Rotary Mechanisms

Thin section bearings for rotary tables, gimbals and positioning systems.

Radar Turntables

Precision rotation for antenna and tracking platforms.

Aerospace Equipment

Compact bearings for airborne optical payloads and gimbals.

Medical Equipment

Precision support for imaging and diagnostic mechanisms.
