Reduced Installation Space
A small section helps fit a rotary bearing into assemblies with tight radial and axial space limits.
Super Thin Section Bearings for Space-Saving Designs
PRODUCTS
Product Categories
ADVANTAGES
Why Choose CHG Super Thin Section Bearings
Applications
Super Thin Section Bearings Appliacitons
Optical Gimbals & Camera Mechanisms
For compact rotating supports where low mass, positioning and available space matter.
Robotics & Lightweight Automation
For small rotary joints, end-effectors and positioning modules after load and stiffness review.
Inspection & Measurement Equipment
For compact scanning and sensing mechanisms with controlled rotation or oscillation.
Semiconductor Handling
For space-limited handling modules, with cleanliness, lubrication and torque requirements reviewed for the environment.
Satellite & Aerospace Mechanisms
For weight-sensitive mechanisms subject to project-specific qualification and environmental validation.
Customize
Custom Super Thin Section Bearing Solutions
By Bearing Number
Send the existing bearing number and reference drawing. CHG will review the envelope, contact geometry and operating requirements.
By Drawing & Space
Provide bore, outside diameter, width, shoulders and fit tolerances, plus the available radial and axial space.
By Load & Motion
Specify radial, axial and moment loads, speed or oscillation angle, duty cycle and shock conditions.
By Precision & Torque
State running accuracy, starting and running torque limits, allowable axial play and preload requirements where applicable.
FAQ
Super Thin Section Bearings FAQs
What are super thin section bearings?
They use a particularly small cross-section relative to the bore to save installation space and weight. Dimensions and performance limits depend on the specific series.
How do I choose the contact design?
Angular contact designs support radial and single-direction axial loads, with opposing support as required. Deep groove designs mainly support radial load. Four-point contact designs can support combined radial, bidirectional axial and moment loads within their limits.
What sizes and materials can CHG supply?
Send the bearing number, drawing or dimensions with units. CHG will confirm the available size, material and configuration for the required duty; a single size range does not apply to all designs.
Which product types are available?
CHG groups super thin section angular contact, deep groove and four-point contact ball bearings under this category. Select the contact type according to loads and the complete bearing arrangement.
Are they suitable for high speed or heavy loads?
Suitability must be checked from the selected bearing data and application. Super thin section bearings are not automatically a high-speed or heavy-load solution; load, speed, lubrication, heat and support rigidity must be reviewed together.
What information is needed for quotation and mounting review?
Provide dimensions, quantity, load directions, speed or oscillation, accuracy and torque requirements, lubrication and temperature. Shaft and housing drawings help assess fits and ring support.
CONTACT US
Need Super Thin Section Bearings for Your Design?
Send your bearing number or drawing, available space, quantity and operating requirements. CHG will help review a suitable super thin section bearing design.
- Three contact designs
- Compact installation support
- Custom and replacement review
Get a quick quote
We typically confirm within 24 hours.
